DIGITAL INTEGRATED CIRCUITS

Contains the most extensive coverage of digital integrated circuits available in a single source. Provides complete qualitative descriptions of circuit operation followed by in-depth analytical analyses and spice simulations. The circuit families described in detail are transistor-transistor logic (TTL, STTL, and ASTTL), emitter-coupled logic (ECL), NMOS logic, CMOS logic, dynamic CMOS, BiCMOS structures and various GASFET technologies. In addition to detailed presentation of the basic inverter circuits for each digital logic family, complete details of other logic circuits for these families are presented.
